| Codice/Code | dxG | L | L1 | Z1 | Z2 | G1 | E | O'RING | Gr. | Pack | Box | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UN72020B | 20x1/2" | 16 | 15 | 3 | 12 | 1" | 42 | 4075 | 75 | 72 | S |  |
| UN72025C | 25x3/4" | 19 | 16.3 | 3 | 12 | 1"1/4 | 52 | 4112 | 97 | 90 | S | |
| UN72032D | 32x1" | 22 | 19.1 | 3 | 12 | 1"1/2 | 59 | 4131 | 147 | 64 | S | |
| UN72040E | 40x1"1/4 | 26 | 21 | 3 | 12 | 2" | 72 | 6162 | 225 | 40 | S | |
| UN72050F | 50x1"1/2 | 31 | 21.4 | 3 | 14 | 2"1/4 | 79 | 6187 | 329 | 30 | S | |
| UN72063G | 63x2" | 38 | 25.7 | 3 | 18 | 2"3/4 | 96 | 6237 | 498 | 12 | S | |
U-PVC Metric passage series
U-PVC material
U-PVC Metric passage series
Dimensional data
| Codice/Code | dxG | L | L1 | Z1 | Z2 | G1 | E | O'RING | Gr. | Pack | Box | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UN72020B | 20x1/2" | 16 | 15 | 3 | 12 | 1" | 42 | 4075 | 75 | 72 | S | |
| UN72025C | 25x3/4" | 19 | 16.3 | 3 | 12 | 1"1/4 | 52 | 4112 | 97 | 90 | S | |
| UN72032D | 32x1" | 22 | 19.1 | 3 | 12 | 1"1/2 | 59 | 4131 | 147 | 64 | S | |
| UN72040E | 40x1"1/4 | 26 | 21 | 3 | 12 | 2" | 72 | 6162 | 225 | 40 | S | |
| UN72050F | 50x1"1/2 | 31 | 21.4 | 3 | 14 | 2"1/4 | 79 | 6187 | 329 | 30 | S | |
| UN72063G | 63x2" | 38 | 25.7 | 3 | 18 | 2"3/4 | 96 | 6237 | 498 | 12 | S | |
Log in or register to view all table data and other content such as documents and 2D/3D and BIM files
Product Related Files
Login or register to download all documents, 2D/3D and BIM files
Overview
Product codes
UN72020BUN72025CUN72032DUN72040EUN72050FUN72063G
Application
Water TreatmentDesalination installationsSwimming poolsNautical sectorWaterworksChemical IndustryFood IndustryIrrigation
Diameter (")
1/2"3/4"1"1"1/41"1/22"
Diameter (mm)
5063
Materials
U-PVC material
Nomina Pressure (PN)
16
Standard
Plain / Threaded BSP
Certifications
